30" Zephyr Treviso Downdraft Ventilation - ZTV-E30AS
Literature
The Treviso Downdraft is chic, simple, and simply spectacular. Out of sight when not in use for those coveted open kitchen sightlines, this one-and-done hidden downdraft has everything you need, and nothing you dont. A sleek, efficient louver makes this a very visually pleasing solution for nearly any kitchen.
Features
- 14" Chimney Rise
- 3-Way Ducting
- Reversible Blower Housing
- 3-Speed Mechanical Slide Controls
- Auto On/Off
- Airflow Control Technology (ACT)
- Optional Recirculating Kit
- Optional ADA-Compliant Up/Down Remote Control
Specification | |
---|---|
Size | 30” |
BLOWER PERFORMANCE | |
Blower CFM (Min. - Max.) | 200 - 600 |
Sones (Min. - Max.) | 2 - 6 |
ACT 390 CFM (Min. - Max.) | 200 - 390 |
Features | |
ACT™ Technology | 390 |
Controls | Mechanical Slide |
Speed Levels | 3* |
Auto On/Off** | Yes |
Lighting | No |
Filters | Stainless Steel Mesh x2 |
14” Chimney Rise | Yes |
Reversible Blower Housing*** | Yes |
3-Way Ducting | Yes |
Recirculating Option | Yes |
DUCT SPECIFICATIONS | |
Left/Right Ducting | 6” Round |
Bottom Ducting | 6” Round |
AC POWER | 120V, 60Hz at Max. 3.2A |
Specification | |
WARRANTY | 2 years parts, 1 year labor |
